| Brand |
Uniarch |
| Model |
IPC-B232-AF40-DL-ECO |
| Max Resolution |
2 MP |
| Sensor |
1/3.0" CMOS |
| Minimum Illumination |
Color: 0.003 Lux (F1.6, AGC ON), 0 Lux with IR on |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| Adjustment Angle |
Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360° |
| S/N Ratio |
> 52 dB |
| WDR |
DWDR |
| Lens |
Focal Length: 4.0 mm | Iris: F1.6 | Type: Fixed |
| Field of View |
H: 67.3° | V: 37.2° | D: 77.8° |
| DORI Distance |
Detect: 73.5 m | Observe: 29.4 m | Recognize: 14.7 m | Identify: 7.3 m |
| Dual-Light Illuminator |
IR: 30 m | Warm Light: 15 m | Wavelength: 850 nm | IR control: Auto/Manual |
| Video Compression |
Ultra 265 / H.265 / H.264 |
| H.264 Code Profile |
Baseline, Main, High |
| Frame Rate |
Main Stream: 1080P @30 fps, 720P @30 fps
Sub Stream: 640×360 / 2CIF / CIF @30 fps |
| Video Bitrate |
128 Kbps – 6144 Kbps |
| Video Features |
Dual streams, ROI support, Up to 4 OSDs, Privacy Mask, U-code support |
| Image Features |
Smart Illumination, 2D/3D DNR, Smart IR, Flip vertical/horizontal/180°, HLC, BLC, Digital Defog, White Balance Auto/Outdoor/Fine tune/Sodium lamp/Locked/Auto2 |
| Audio |
Built-in mic, G.711U/A, 64 Kbps, 8 kHz sampling, Suppression support |
| Detection & Events |
Motion, Audio, Human body detection 2.0, Watermark, IP filtering, RTSP/HTTP authentication |
| Network |
RJ45 10/100 Mbps Ethernet, ONVIF S/T, APP & Client support, Web browser live view |
| Protection |
IP67, 4 KV surge protection |
| Power |
PoE (IEEE 802.3af), Max 3.5 W |
| Dimensions & Weight |
196.5 × 73 × 72.9 mm | 0.22 kg |
| Material |
Graphene + Plastic |
| Operating & Storage Environment |
-30 ℃ to 60 ℃, ≤ 95% RH (non-condensing) |
