| Brand |
Uniarch |
| Max Resolution |
2 MP |
| Sensor |
1/3.0" CMOS |
| Minimum Illumination |
Color: 0.005 Lux (F1.6, AGC ON), 0 Lux with IR on |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| S/N Ratio |
> 52 dB |
| WDR |
DWDR |
| Lens |
Focal Length: 2.8 mm, Iris: F1.6, Type: Fixed |
| Field of View |
H: 85.1° | V: 46.6° | D: 95.5° |
| DORI Distance |
Detect: 51.4 m | Observe: 20.6 m | Recognize: 10.3 m | Identify: 5.1 m |
| Dual-Light Illuminator |
IR: 30 m | Warm Light: 15 m | Wavelength: 850 nm | IR control: Auto/Manual |
| Video Compression |
Ultra 265 / H.265 / H.264 |
| H.264 Code Profile |
Baseline, Main, High |
| Frame Rate |
Main Stream: 1080P @30 fps, 720P @30 fps
Sub Stream: 640×360 / 2CIF / CIF @30 fps |
| Video Bitrate |
128 Kbps – 6144 Kbps |
| Video Features |
Dual streams, ROI up to 8 areas, Up to 4 OSDs, Privacy Mask, U-code support |
| Image Features |
2D/3D DNR, Smart IR, Flip vertical/horizontal/180°, HLC, BLC, Digital Defog, White Balance Auto/Outdoor/Fine tune/Sodium lamp/Locked/Auto2 |
| Audio |
Built-in mic, G.711U/A, 64 Kbps, 8 kHz sampling, Suppression support |
| Detection & Events |
Motion, Audio, Human body detection 2.0, Watermark, IP filtering, RTSP/HTTP authentication |
| Network |
RJ45 10/100 Mbps Ethernet, ONVIF S/T, APP & Client support, Web browser live view |
| Protection |
IP67, 4 KV surge protection |
| Power |
PoE (IEEE 802.3af), Max 3.5 W |
| Dimensions & Weight |
Ø118 × 100 mm | 0.19 kg |
| Material |
Graphene + Plastic |
| Operating & Storage Environment |
-30 ℃ to 60 ℃, ≤ 95% RH (non-condensing) |
