| Brand |
Uniarch |
| Model |
IPC-B134-AF40-DL- ECO |
| Max Resolution |
4 MP |
| Sensor |
1/3.0" CMOS |
| Min. Illumination |
Color: 0.003 Lux (F1.6, AGC ON), 0 Lux with IR on |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| Adjustment Angle |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| S/N |
> 52 dB |
| WDR |
DWDR |
| Focal Length |
2.8 mm | 4.0 mm |
| Iris |
F1.6 |
| Iris Type |
Fixed |
| Field of View (H/V/D) |
H: 93.2° | 77.4° | V: 51.5° | 41.9° | D: 108° | 90.5° |
| DORI Distance |
Detect: 63.0 m | 90.0 m | Observe: 25.2 m | 36.0 m | Recognize: 12.6 m | 18.0 m | Identify: 6.3 m | 9.0 m |
| Illuminator |
Dual light | IR: 30 m | Warm Light: 15 m | Wavelength: 850 nm | Auto/Manual control |
| Video Compression |
Ultra 265, H.265, H.264 |
| Frame Rate |
Main Stream: 4 MP (2560 × 1440), max. 25 fps; 3 MP (2304 × 1296), max. 30 fps; 1080P (1920 × 1080), max. 30 fps
Sub Stream: 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps |
| Video Bitrate |
128 Kbps to 6144 Kbps |
| OSD & Privacy |
Up to 4 OSDs | Up to 4 Privacy Mask areas | ROI support | Dual stream |
| Image Features |
Smart Illumination, 2D/3D DNR, Smart IR, Flip vertical/horizontal/180°, HLC, BLC, Digital Defog, White Balance Auto/Outdoor/Fine tune/Sodium lamp/Locked/Auto2 |
| Audio |
G.711U/A, 64 Kbps, 8 kHz sampling, Built-in mic, Suppression support |
| Network |
1 × RJ45 10/100 M Ethernet, ONVIF (Profile S/T), APP & Client support, Plug-in free live view (Chrome 57+, Firefox 58+, Edge 16+) |
| Protection |
IP67, 4 KV surge protection |
| Power |
PoE (IEEE 802.3af), Max 3.5 W |
| Dimensions & Weight |
140 mm × 61 mm × 65 mm | 0.16 kg |
| Material |
Graphene + Plastic |
| Operating & Storage Environment |
-30 ℃ to 60 ℃, Humidity ≤ 95% RH (non-condensing) |
