| Brand |
Uniarch |
| Model |
IPC-B134-AF40-ECO |
| Max Resolution |
4 MP |
| Sensor |
1/3.0" CMOS |
| Minimum Illumination |
Color: 0.003 Lux (F1.6, AGC ON), 0 Lux with dual-light |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| S/N Ratio |
> 52 dB |
| WDR |
DWDR |
| Lens |
Focal Length: 2.8 mm | 4.0 mm, Iris: F1.6, Type: Fixed |
| Field of View |
H: 93.2° / 77.4° | V: 51.5° / 41.9° | D: 108° / 90.5° |
| DORI Distance |
Detect: 63.0 m / 90.0 m | Observe: 25.2 m / 36.0 m | Recognize: 12.6 m / 18.0 m | Identify: 6.3 m / 9.0 m |
| Dual-Light Illuminator |
Warm light: 15 m (49.2 ft) | IR: 30 m (98.4 ft) | Wavelength: 850 nm | IR control: Auto/Manual |
| Video Compression |
Ultra 265 / H.265 / H.264 |
| H.264 Code Profile |
Baseline, Main, High |
| Frame Rate |
Main Stream: 4 MP @25 fps, 3 MP @30 fps, 1080P @30 fps
Sub Stream: 640×360 / 2CIF / CIF @30 fps |
| Video Bitrate |
128 Kbps – 6144 Kbps |
| Video Features |
Dual streams, ROI, Up to 4 OSDs, Privacy Mask, U-code support |
| Image Features |
Smart Illumination, 2D/3D DNR, Smart IR, Flip (vertical, horizontal, 180°), HLC, BLC, Digital Defog, Area White Balance |
| Audio |
Built-in mic, G.711U/A, 64 Kbps, 8 kHz sampling, Suppression support |
| Detection & Events |
Motion, Audio, Human body detection 2.0, Watermark, IP filtering, RTSP/HTTP/ONVIF authentication |
| Network |
RJ45 10/100 Mbps Ethernet, ONVIF S/T, APP & Client support, Web browser live view |
| Protection |
IP67, 4 KV surge protection |
| Power |
PoE (IEEE 802.3af), Max 3.5 W |
| Dimensions & Weight |
140 × 61 × 65 mm | 0.16 kg |
| Material |
Graphene + Plastic |
| Operating & Storage Environment |
-30 ℃ to 60 ℃, ≤ 95% RH (non-condensing) |
