| Brand |
Uniarch |
| Model |
IPC-T134-AF28-ECO |
| Max Resolution |
4 MP |
| Sensor |
1/3.0" CMOS |
| Minimum Illumination |
Color: 0.003 Lux (F2.0, AGC ON), 0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| Adjustment Angle |
Pan: 0°–360°, Tilt: 0°–80°, Rotate: 0°–360° |
| S/N Ratio |
> 52 dB |
| WDR |
DWDR |
| Lens |
Focal Length: 2.8 mm, Iris: F2.0, Type: Fixed |
| Field of View |
H: 97° | V: 54.9° | D: 111.9° |
| DORI Distance |
Detect: 63.0 m | Observe: 25.2 m | Recognize: 12.6 m | Identify: 6.3 m |
| IR Illuminator |
Up to 30 m (98.4 ft), 850 nm, Auto/Manual |
| Video Compression |
Ultra 265 / H.265 / H.264 |
| H.264 Code Profile |
Baseline, Main, High |
| Frame Rate |
Main Stream: 4 MP @25 fps, 3 MP @30 fps, 1080P @30 fps
Sub Stream: 640×360 / 2CIF / CIF @30 fps |
| Video Bitrate |
128 Kbps – 6144 Kbps |
| Video Features |
Dual streams, ROI, Up to 4 OSDs, Privacy Mask, U-code support |
| Image Features |
2D/3D DNR, Smart IR, Flip (vertical, horizontal, 180°), HLC, BLC, Digital Defog, Area White Balance |
| Audio |
Built-in mic, G.711U/A, 64 Kbps, 8 kHz sampling, Suppression support |
| Detection & Events |
Motion, Audio, Human body detection 2.0 |
| Network |
RJ45 10/100 Mbps Ethernet, ONVIF S/T, APP & Client support, Web browser live view |
| Protection |
4 KV Surge Protection |
| Power |
PoE (IEEE 802.3af), Max 2.5 W |
| Dimensions & Weight |
Ø118 mm × 100 mm | 0.19 kg |
| Material |
Plastic |
| Operating & Storage Environment |
-30 ℃ to 60 ℃, ≤ 95% RH (non-condensing) |
