| Brand |
Uniarch |
| Model |
IPC-B234-AF40-ECO |
| Max Resolution |
4 MP |
| Sensor |
1/3.0" CMOS |
| Minimum Illumination |
Color: 0.01 Lux (F2.0, AGC ON), 0 Lux with IR on |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 to 1/100000 s |
| S/N Ratio |
> 52 dB |
| WDR |
DWDR |
| Lens |
Focal Length: 4.0 mm, Iris: F2.0, Type: Fixed |
| Field of View |
H: 74.6° | V: 40.5° | D: 89.1° |
| DORI Distance |
Detect: 90.0 m | Observe: 36.0 m | Recognize: 18.0 m | Identify: 9.0 m |
| IR Illuminator |
Supplemental IR light, distance up to 30 m (98.4 ft), wavelength 850 nm |
| Video Compression |
Ultra 265 / H.265 / H.264 |
| H.264 Code Profile |
Baseline, Main, High |
| Frame Rate |
Main Stream: 4 MP @25 fps, 3 MP @30 fps, 1080P @30 fps
Sub Stream: 640×360 / 2CIF / CIF @30 fps |
| Video Bitrate |
128 Kbps to 6144 Kbps |
| Video Features |
Dual streams, ROI, Up to 4 OSDs, Privacy Mask, U-code support |
| Image Features |
Smart Illumination, 2D/3D DNR, Smart IR, Flip (vertical, horizontal, 180°), HLC, BLC, Digital Defog, Area White Balance |
| Audio |
Built-in mic, G.711U/A, 64 Kbps, 8 kHz sampling, Suppression support |
| Detection & Events |
Motion, Audio, Human body detection 2.0, Watermark, IP filtering, RTSP/HTTP/ONVIF authentication |
| Network |
RJ45 10/100 Mbps Ethernet, ONVIF S/T, APP & Client support, Web browser live view |
| Protection |
IP67, 4 KV surge protection |
| Power |
PoE (IEEE 802.3af), Max 3.1 W |
| Dimensions & Weight |
196.5 × 73.0 × 72.9 mm | 0.22 kg |
| Material |
Graphene + Plastic |
| Operating & Storage Environment |
-30 ℃ to 60 ℃, ≤ 95% RH (non-condensing) |
